CHANGHUA CHEN YING OIL MACHINE CO., LTD.
Product Description :
1. KGC and KGCP types are suitable for grease NLGI grades 000, 00 and 0.
2. Recommend using a grease gun for filling with lubricant from grease inlet. It can avoid air or impurities dropping into the reservoir.
3. KGC and KGCP types are controlled by PLC (Programmable Logic Controller). It can work with CV type Progressive Feeders which can supply fixed volume of grease. CV type Progressive Feeders can assure each of lubrication point has equal amount of grease.
4. Pressure switch can be added on request for checking if the piping works normally. The standard setting is at 60 bars and the standard specification is NC (Normally Closed) contact, which means if the pressure doesn't reach the default setting, it sends continuous signals. NO (Normally Open) contact is available on request.
5. Magnet Level Switch is also an optional accessory that can be added upon request. It sends continuous signal automatically when the grease level is lower than the minimum level.
6. For the first time use, slightly press the Feed button (F button) to feed grease immediately. F button can be used as manually grease feeding for no more than 3 minutes.
7. AC110V and AC220V motors have thermal controls. When the motor temperature reaches 100℃, the sensor will be on to stop the motor continue running about 5 minutes.
8. It has a pressure gauge that the operator can check the pressure easily.
9. It can be used for the machines requiring strictly rationing grease flow. It usually works with rubber or plastic machines, press machines, machine centers, woodworking machines, etc.
SOLIDWIZARD TECHNOLOGY
Product Description :
出色的產品始於出色的設計，因此，SOLIDWORKS為您提供將 設計概念轉化為 零件和組合件的各種工具 。 全球有470多萬名 設計師、工程師、經理和製造商在使用SOLIDWORKS·它有助 於推動更智慧、更快速和更輕鬆的產品開發。SOLIDWORKS具有以下行業領先功能，幫助眾多公司實現創新：<br />
• 概念設計：專為工業設計和機械裝置設計打造的工具。<br />
• 曲面造型：高級工具確保您能夠迅速建立任何形狀。<br />
• 直接編輯：直接操作 3D CAD 幾何體。<br />
• 快速建立2D 工程圖：同步與 3D 模型設變。<br />
• 大型組合件：能夠處理超大型設計，甚至包含幾十萬個零件。<br />
• 逆向工程：用於點雲和網格資料曲面製作和操作的工具。<br />
• 專用設計功能：模具設計、鈑金、焊件、管路和電氣佈線。<br />
• 自動化：免費 API、批次處理流程可配置在產品和工程圖。<br />
• 創成式設計：根據功能和製造需求，自動開發零件形狀。<br />
• CAD 庫：超過 100 萬個市購件、電氣專案和符號可添加到您的設計中。<br />
• 線上目錄：提供使用者建立的零組件和透過認證的供應商零組件。<br />
• 導入/匯出：以 2D 和 3D 方式導入/匯出所有主要格式。<br />
• 直接互通性：用於非原生 CAD 文件的 SOLIDWORKS 3D<br />
Interconnect。<br />
• 可製造性設計 (DFM)：檢查干涉、公差和工程圖標準。<br />
Fulson Industrial Co., Ltd
Product Description :
This high precision surface and form grinder has been specially developed and improved in recent years.
The tool cabinet in machine base is specially designed for operator’s convenience (618m).
The interlock between electrical cabinet door and power supply is established to ensure safe operation.
The maximum distance from table surface to spindle centerline is 18" (450mm) which provides more clearance for grinding.
The sping loaded type table travel stops will dampen theovertravel caused by abnormal operations (618m).
The optimum span of double V crossfeed guideways is designedbased on bending moment, kinematics supporting force.
All essential castings are mode of high grade of meehanite castiron that is stress relieved through annealing to eliminateinternal stress.
With the greatest stiffness and stability of the castings, this machine is suitable for both precision surface grinding and formgrinding .
This grinder is offered with one-full-year limited warranty formechanical and electrical parts .
LEADWELL CNC MACHINES MFG., CORP.
Product Description :
Twin spindle & twin turret design, it can turn the different parts on the spindle and identical parts on both spindles at the same time. Integrated with 3-axis robot arms, to reach different OP and automation requested. Considering the turning efficiency, with automation high-speed robot reduces the loading/unloading time, with a high rigidity stricture design to increase the stability. On the other hand, the multiple types of robot arms will be able to satisfy the different demands of the client.
Max. swing: 290mm
Max. turning diameter: 290mm
Max. turning length: 220mm
X-axis travel: 195+5mm
Z-axis travel: 300mm
Spindle speed: 3500rpm
Spindle nose: A2-6
Chuck size: 10"
Spindle motor power: 11/15kw
Number of tool stations: 12T
BENIGN ENTERPRISE CO., LTD.
Product Description :
• Hydraulic longitudinal feed. Direction changed by sensor & solenoid valve.
• Automatic cross feed. Direction changed by stopping dog and limit switch.
• Manual vertical feed
• Saddle type
• Automatic lubrication
• Longitudinal: one flat and one V way
• Cross: 2 V way
• Optional AD5 automatic down feed and magnetic chuck
ZHAO YI HSIN INDUSTRIAL CO., LTD.
Product Description :
Providing clean compressed air without energy consumption
No power required
Applying characteristics of compressed air, hydromechanics and physical principles to design internal structure.
Consumable-free, maintenance-free
Exclusive patented structural design can separate moisture from compressed air without consumables.
Efficiency of air drying and moisture filtration: 99%
Patented high efficiency water-cooled heat exchanger and special air-water separation structure.
High quality, durable, and longevity up to 10 years
No compromise on quality, the product is made in Taiwan.
No electronic and other energy-driven device
Suitable for those who have special needs for compressed air.
