TAIWAN MACHINE TOOL CO., LTD.
Product Description :
The Machine Center for next generation — TLV-850II
Applied field: general hardware processing, mold processing, precision parts
TLV-850II is known for its stability and capability of manufacturing with its high rigidity, which adopts the advantages from TLV-850. Furthermore, it applies the structure which fits the current trend.
－T-slot is used with the common specialization: 18mm
－Z-axis is adopted with the design of high rigidity, a bigger motor, and the strengthened structure so that it leads to perfect swarf performance.
－The tool magazine is well designed to provide the best stability.
－A stronger saddle and an enlarged base frame are also installed to stabilize the performance on cutting.
QUASER MACHINE TOOLS, INC.
Product Description :
MF700’s design concept is to strengthen Column-moving C frame structure, and separate linear & rotary axes, optimize it with FEMA analyze, the advantages are high rigidity in structure, high precision in machining, and operator friendly. To separate linear & rotary axes is to minimize the following errors and ensure machining accuracy, on top of that, the transmission mechanism/components is away from working area which can reduced parts failure from pollution of coolant and chips.
The linear axes has a cross-frame design, the wide-span column and large-size linear way blocks provides excellent stability during high-speed cutting. Rotary table is intergraded with bridge type column, this compact design can bring us smaller footprint and maximize working envelope.
Rotary table with tailstock support can increase the load capacity which is capable up to 500kg, maximum swing for workpiece is 700mm and height is up to 500mm.
The standard worm gear/wheel and encircling brake design provide high rigidity and lock-force. For different application like high speed demand in aerospace, it can be upgraded with dual Direct Drive Motor.
Operator friendly design with 2 wide open doors are not only easier for operator but also easier for automation upgrade. More thoughtful is we offer three different types of top guards for different work environment, telescope type, solid top cover and open top.
New base design allow chips fall onto conveyor directly, reduce 50% your chip cleaning time.
HON JAN CUTTING TOOLS CO., LTD.
Product Description :
●Internal and external threading for both left-thread and right-thread with one tooling
●Safe machining operation and easier to reach the bottom inside the blind holes
●Evacuate the chip more efficiently than the traditional milling process. shank: 20mm~40mm , Internal Thread Insert: 12I , 14I, 21I, 30I , 40I , External Thread Insert: 14E, 21E, 30E , 40E
SING CHIUN ENTERPRISE CO.,LTD.
Product Description :
(1) Great tensile performance, great camber.
(2) Thermal resistance range:-15℃~105℃ , Protection
degree IP68.
(3) Inner conduit is made of iron metal with zinc plating,
out layer is covered with PVC, with of waterproof
and dust proof.
(4) PT705 (3/8"~ 1 1/4") Inner conduit with copper
earth wire.
(5) According to IEC Section 351, the conduit must be
additionally attached with one grounding cable
when PT705 (1 1/2"~ 4") is constructed.
(6) Apply to conduit protection of electrical equipment
under UL standard, detection instrument, industrial
equipment and hardware work piece.
(7) Apply to electrical conduit for heavy industrial
machine motor, petrified and chemical machine,
plastic manufacturing building, power transformer
and ship manufacturing.
EANG LIAN CORPORATION
Product Description :
Professional Abrasive Brushes-Specifically designed for mechanical finishing tasks .
Specifically designed for mechanical finishing tasks .
That can be used in both conditions: dry grinding or wet grinding;
ideal for deburring parts in which the burred edges are in the same plane. Such as: deburring, sharp edge removal, radiusing,
edge contouring, de-fuzzing .
YINSH PRECISION INDUSTRIAL CO., LTD.
Product Description :
YINSH PRECISION IND . CO ., LTD . specializes in the production of superfine balanced locknuts for high speed machine tool spindles. SBL series is designed for all configurations of internal and direct drive spindles. Inner threads, outer skirts, clamping and trailing rims are all precision ground. Coupled with balanced adjustment screws, these locknuts stay perfectly balanced at high speeds. Made of high grade SCM440 alloy steel and hardened to HRC 48°-52°, rigidity and precision at high speeds is given. All locknuts can be fitted with adjustment screw hole screw-in plugs(option), eliminating high frequency noise and subsequent vibration.
HO CHEN MACHINERY & ELECTRIC IND. CO., LTD.
Product Description :
XYZ axes travel: 500x400x185mm (20"x16"x7") inch
U axis travel: 300mm (12") inch
Z axis single travel: 400 mm (16") inch
Work table: 800x450 mm (31"x18") inch
Max. Workpiece: 1250x650x390 mm (49"x26"x15") inch
Max. Workpiece weight: 1400 kg
Max. Electrode weight: 185 kg
Machine net weight: 2100 kg
Oil level: 110-360 mm (4"-14") inch
Packing Size(LxWxH)：2340x2320x2500 mm (92"x91"x98") inch
Work Table to platen:
1. Z axis single travel: 230-630 mm (9"x25") inch
2. UZ axis: 230-715 mm (9"x28") inch
Filter： 1
Paper filter：2
Capacity：550 Liters
Machine Features
> Windows CE controller
> A dialog window with picture description.
> Special repaired frames to quicken the maintenance speed.
> Close-loop design of digital feedback on three axes of the machine significantly increases positioning precision and ORBIT-CUT machining accuracy and efficiency.
> Simple operation interface.
> Common function keys are located on the operational panel for direct use.
> Hot key setting.
> ATC (automatic tool change) and C-axis 360° index can be installed; the process of coarse machining to ultra-fine machining can be completed at one time.
> Dialogue diagram provides various hole-expanding modes such as quick search of edge, centers and datum marks.
> Rich color graphic (the same resolution as a PC screen).
> Automatic multi-step machining (coarse, medium coarse, medium fine, fine, superfine)—up to 10 steps.
> Unlimited number of machining conditions can be saved as machining archives. Each set of machining conditions can be edited, modified or stored. They are easy to edit and easy to find.
> Automatic origin search and multi-point coordinate memory capability.
> 1/2 design capability, ARC automatic discharge waveform detection and automatic adjustment.
> Automatic center position detection, automatic compensation, search of hole center and deepest point; fixed hole machining (cyclic mode, independent mode), which is suitable for different machining conditions; Radial, circular, square, linear (vector), coning, 45° hole-expanding machining.
> Three-axis beeline, two-axis arc, three-axis helix.
> Chinese/English versions interface, metric/British system switch and Z-axis quick up, quick down, slow up and slow down capability.
> Lateral machining, three axes, six directions (plane rotation).
> All alarms describe the source, date and exact time of problem occurrence.
> Optical scale is applied for close-loop position control, enabling extreme position for machining.
> Automatic editing—settings can be done according to type of material, work piece size, machining depth, one side die clearance, final current and rate of electrode wear.
> CNC models possess conventional capability of consistent level of energy discharge, achieving stable and rapid machining and smooth high quality on machining surface while the rate of electrode wear is still low.
> Monitor page indicates machining path and orbital pattern in use.
DKSH Taiwan Ltd.
Product Description :
The PC R series evaporators have a heating system based on a heat pump and operate under vacuum at 5kPa and around 30°C (86°F).
Heat exchange occurs within a conical jacket, and the boiling chamber inside part is cleaned by internal scrapers that continuously stir concentrate. This configuration is designed to produce a concentrate with a high final concentration and a distillate with low conductivity.
•From 0,1 to 2 m3/day – 0.02 to 0.37 US gpm of distillate
•Dramatic reduction of volumes and disposal costs
•Matter recovery
Extremely suitable when:
•the wastewater has a high initial content of dissolved or suspended solids
•the wastewater is already pre-concentrated
•the daily volumes are relatively small
•the distillate has to be of the highest quality
•the concentrate has to be recycled
RICH SOU TECHNOLOGY CO., LTD.
Product Description :
The door equipped with PENUMATIC valve safe door opening and closing.
The double bevel mechanism has has rail exchange function.When one shaft is performing parts replacement at the outside for saving time.
Steel shot recycling system: Screw Conveyor is equipped with a sieving screen for separating big grits,which will be emitted automatically.
An air operated steel shot separator built on the top of elevator,fully separates steel shot from heavy grits and dust to reduce the consumption of water resisting parts.
A Being Kou Tools Co., Ltd.
Product Description :
After becoming frustrated by the existing coolant hose products on the market; all of which suffered from a variety of shortcomings, Arnold Lockwood conceived the idea for the modular hose that became Loc-Line®. The shortcomings of the existing products included, metal coolant hoses that would not stay where they were positioned and plastic hoses with metal positioning rods that broke.
In 1981 Lockwood Products was formed to develop and distribute Loc-Line®. The first products were shipped in August of 1983.
Loc-Line® quickly became the standard for coolant delivery around the world and was easily recognized by our Blue and Orange colors and consistent high quality.
Today Loc-Line® is still the leader in modular hose and continues to innovate in the modular hose field. Loc-Line® is used not only as a coolant hose but for air delivery, smoke and dust removal vacuum systems, agriculture, third arm uses including positioning cameras, lights and items for handicap assist.
We here at Lockwood Products, Inc are proud to have originated the modular hose Loc-Line© that remains the standard for the industry worldwide!
Please visit one of our distributors today and see for yourself why Loc-Line remains the best and most versatile solution in the world today!
