PROTH INDUSTRIAL CO., LTD.
Product Description :
PSGC-50100E Features :
1. E - Environmentally friendly, Belt-driven and quiet.
2. The controller adopts graphic display, and the operation is simple and easy to learn.
3. Dressing on the table for efficient circumferential and face dressing.
4.Machine drive : Three-axis servo.
7-LEADERS CORP.
Product Description :
End Mills for Aluminium- 3 Flutes
Design with sharp cutting edge, high removal cutting geometry, and fine grinding smooth surface to prevent sticking problem.
Higher finishing of cutting edge to have better surface roughness after processing.
Application for roughing and finishing in various Aluminium.
CHIEN CHENS MACHINERY CO., LTD.
Product Description :
Specification
Table size: 1515 x 470 mm
Longitudinal travel: 1300 mm
Cross travel: 600 mm
Y slide way width: 720 mm
Z Slide high: MAX 760 mm
Z Slide way width: 420 mm
Spindle taper: NT#50(BT)
Spindle motor: 7.5HP / 2P
Spindle speed: 62~1100 RPM
Feeding speed: 10~6000 mm/min
Ballscrew: Ø32 mm C5
Net weight: 3200 kgs
Fulson Industrial Co., Ltd
Product Description :
This machine is the crystallization of the technology that Fushun has carefully researched for many years. It has a stable appearance and a strong structure. Various operating handles and movable operating panels are within the operator's best line of sight and the most comfortable operating position. This is in line with the ergonomic design. Excellent models, providing you with higher work efficiency.
Spindle mechanism: The spindle is supported by five ultra-precision beveled ball bearings. Stable and strong main shaft structure, can withstand heavy load grinding.
AC servo motor lift drive: C3-level drive screw, driven by AC servo motor, with large torque, fast speed, and high positioning accuracy. With the full CNC system, the feed accuracy can reach 0.0001mm or 0.001mm.
Two lines and one hard track: Z-axis and Y-axis purchase high-precision line rails, and cooperate with high-precision ball screws, which can make the action smooth without lag; , maintaining accuracy without distortion.
Front and rear transmission speed control: The continuous movement speed of the saddle is driven by AC servo motor to obtain good surface grinding accuracy.
Samwell Testing Inc.
Product Description :
PSV QTec Scanning Vibrometers take full-field vibration mapping to the next level with unrivalled optical sensitivity! Their innovative, patented QTec® technology uses multi-path interferometry based on infrared (SWIR) laser granting high-fidelity measurements on all surfaces from DC to 25 MHz. PSV QTec significantly reduce testing time - especially on dark, biological, rotating or moving objects, determining operational deflection shapes and Eigenmodes for NVH, acoustics, structural dynamics, ultrasonics, FEM validation and NDT.
BEST DIAMOND INDUSTRIAL CO., LTD.
Product Description :
Compared to resin bond and metal bond wheels, Electroplated Grinding Tools are noted for relatively large grit protrusion and higher abrasive concentration. This results in very free cutting properties and in high stock removal capacity. Besides, these tools are noted for:
1. Allow special shapes and profile tools to be made at short notice.
2. Cause very little change on wheel shape after used, suitable for precision grinding.
Application and Processing Material for Electroplated Grinding Tools :
1. Internal grinding: Suitable for the internal grinding of carbide and High Speed Steel. The smallest diameter of our electroplating area is 0.3mm so it could be used in drilling for fined ceramics.
2. Jig grinding: Mostly used in fined ceramics processing and precision grinding for quartz. Customized items are also provided to cater your needs. Common grit size is #80~#325, good for rough and fine processing.
3. Touchscreen Processing: Drilling and chamfering for the glass panel of the smart phone and tablet computer. In order to improve work efficiency, we could also combine different grit sizes in the same diamond mounted point.
4. Grinding for Cutting tools: Normal end-mill grinder and drill grinder go with electroplated wheel. Carbide can be ground by diamond wheel and High Speed Steel could be ground by CBN wheel. Bowl-shape wheel with standard specification is also provided, suitable for the grinding of turning tools.
5. Precision grinding: Electroplating can produce wheel of different shapes without deforming it. Therefore, it is suitable for precision grinding or trimming aluminum oxide wheel.
6. Gem grinding: shape grinding for gem, semi-precious stones, shell and jade.
MATRIX PRECISION CO., LTD.
Product Description :
2080/3080 applies the FANUC controller and high speed grinding spindle, it will design the tooth profile and grinding parameters flexibly through the intelligent
conversations window software. The machinable workpieces include the standard worms
(ZK, ZI, ZN & ZA), dual-lead worms, ZC (Niemann) worms, thread plug gauges and rolling dies. The high efficiency and high-precision machining performance meet the worldwide top brand products in this field. 2080/3080 is your best choice.
TAIWAN ASAHI DIAMOND INDUSTRIAL CO., LTD.
Product Description :
* Processing Method｜Cutting Tools
* Applications｜Die and Mold
* Customized tool design, lower cutting resistance and torque and better lifetime compared to conventional tools. Reduces the times of tool changes; Suitable for production-related molds.
* Processing Material | NAK80, SKD61, STAVAX, DC53, ELMAX, PD613, HSS, DRM, YXR3, SKHHAP
Graphite, aluminum alloy ADC12, carbon fiber reinforced plastic CFRP, glass fiber GFRP, chemical nickel, copper, oxygen-free copper, various plastic materials PU, etc.
